    Firestone Air Rubber Bellow W01-R58-4055 Air Spring Suspension 4×M10 Studs

    Ask Lasest Price
    Brand Name : GUOMAT
    Model Number : W01-R58-4055
    Certification : ISO/TS16949, ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, Western Union
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Firestone Air Rubber Bellow W01-R58-4055 Air Spring Suspension 4×M10 Studs

    Firestone Air Rubber Bellow W01-R58-4055 Air Spring Suspension 4×M10 Studs


    2B8×2T Air Spring Information


    Bottom Plate Alignment: Parallel
    Bottom Plate Center To Center Diameter: 156 mm
    Bottom Plate Diameter: 184 mm
    Bottom Plate Hole Quantity: 4
    Bottom Plate Type: Steel
    Top Plate Alignment: Parallel
    Top Plate Center To Center Diameter: 156 mm
    Top Plate Diameter: 184 mm
    Top Plate Hole Quantity: 5
    Top Plate Type: Steel
    Bellow Maximum Diameter:230 mm
    Expanded Height: 72 mm
    Compressed Height: 225 mm
    Spring Type: Double Convoluted
    Air Inlet: 1/2 BSP
    Nut/Blind Nuts Type: 4×M10

    Alternative Items


    FIRE-STONE NO.

    W01-R58-4055, W01R584055, W01/R58/4055

    w01-r58-4055, w01r584055, 4055, 8x2 , 8''x2 , 8'x2

    FRUEHAUF NO.F48054, M80A04, F 48054, M 80A04
    LOHR NO.A06030604, A 06030604
    SAMRO NO.H2500021, H2500188, H 2500021, H 2500188, H 250 0021, H 250 0188
    SISU TRUCK NO.1531110600, 153 111 0600
    DUNLOP NO.SP1490, SP918, SP 1490, SP 918
    CONTITECH NO.FD 138-18 DS, FD138-18 DS, FD128 18 DS, FD 138 18 DS
    NORGREN NO.M/31082, M 31082, M31082
    PARKER NO.9109011


    Product Applications


    • Gate Valve Operator
    • Glue Coating Machine
    • Web Tightening Tool
    • Stripper
    • Tool Spring Driver
    • Quenching Drain Driver
    • Paper Mill
    • Pickling Tank Driver


    FAQ


    Q: How do you guarantee quality?
    A: We have testing on aging, hardness, bending, tension, viscosity, rheology, water inspection, bursting, fatigue, etc.


    Q: What's your advantage?
    A: (1) Resonable price, good service
    (2) Reliable quality, long working life
    (3) Quick and safe modes of payment
    (4) Ships items timely and quickly
    (5) Our products are exported to most countries in the world


    Q: Can you print my logo on inner box and outer box?
    A: Yes. We can do it, but it has MOQ.

    Q: Is the sample available?
    A: YES. Usually we send the samples by TNT, DHL, FEDEX or UPS, it will take around 3-7 days for our customers to receive them, but charge all customer will cost related to the samples, such as sample cost and airmail freight.



    Company Profile

    Guangzhou Guomat Air Spring Co., Ltd. is founded in 2008, the company covers an area of 20000 square meters, registered capital is 10 million yuan, the existing various types of professional and technical personnel is 85 people.The company is located in Guangzhou, about 15min's drive from Baiyun Airport. and our main products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles' seat, luxurious car and industrial machine field.
