    Suspension Air Spring W01-358-6910 Firestone Double Convoluted Air Spring

    Ask Lasest Price
    Brand Name : GUOMAT
    Model Number : 2B6910P34
    Certification : ISO/TS16949, ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, Western Union
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Suspension Air Spring W01-358-6910 Firestone Double Convoluted Air Spring

    Suspension Air Spring W01-358-6910 Firestone Double Convoluted Air Spring


    Product Information


    Air hole/air inlet/air fittings

    Air hole/air inlet: G3/4
    The distance between the air hole and the screw: 38mm

    Top plate screw (nut) teeth: 2XM8×1.25
    The screw center distance of the top cover plate: 89mm
    Screw (nut) teeth of the bottom cover plate: 2XM8×1.25
    The screw center distance of the bottom cover plate: 89 mm

    Cover plate

    Top plate diameter: 160 mm
    Diameter of the bottom cover: 160 mm

    Bell rubber bellows

    Rubber Bellow Diameter: 224mm
    Max Diameter: 251mm
    Stroke: from 72mm to 260mm

    Bumper block/bumper block

    No bumper block

    Belt loop/Belt loop

    With belt loop: one piece of belt loop
    Min. pressure: 0 bar
    Return force to min.height: ≤200N
    Overall weight with clamped plates: 3.2kg


    Refer Number


    Firestone Bellows Number: 20
    Goodyear Part Number: 2B9-200, 2B9200
    Goodyear Bellows Number: 578-92-3-202
    ContiTech Number: 161008, 64267, FD 200-19 320
    ContiTech Bellows Number:FD 200-19
    Granning Number: 1371, 2726
    Hendrickson Number: 45843003, 45843-003, 458433, 45843-3, B458433, B8768, S458433, S8768, S-8768
    Hendrickson Trailer Number: S-8768
    Hendrickson Truck Number: 45843-3
    IHC Number: 554783C1
    Loadguard Number: SC2011
    Neway Number: 57006910
    Ridewell Number: 1003586910C
    Taurus Number: AS2186910
    Triangle Part Number: 4320
    Triangle Bellows Number: 6325
    Volvo Number: 3918343
    Watson & Chalin #: AS-0001, AS0001
    Note: Diesel Nacional AX-8127-19
    UPC: 767555002988
    MPN: W013586910



    Other Types Of Firestone Air Spring
    Single Convoluted
    Fire stone : W01-358-7731Fire stone : W01-M58-6165
    Fire stone : W01-358-7564Fire stone : W01-358-7598
    Fire stone : W01-M58-6374FIRE STONE FLEX 115
    FIRE STONE W01-358-0118Fire stone : W01-358-7008
    Fire stone: W01-358-7009Fire stone. W01-358-7103
    Fire stone. W01-358-7112
    Double Convoluted
    FIRE STONE W01-095-0111FIRE STONE W01-358-7325
    FIRE STONE W01-358-7327Fire stone : W01-358-7325
    Fire stone : W01-M58-6353FIRE STONE W01 M58 7894
    Fire stone : W01-358-6926Fire stone : W01-358-6910
    Fire stone : W01-358-6902Fire stone : W01-358-6927
    Fire stone : W01-358-6943Fire stone : W01-358-6946
    Fire stone : W01-358-6945Fire stone : W01-M58-7679/20C2
    Fire stone:W01-358-6948FIRE STONE W01-358-6951
    FIRE STONE W01-358-6952Fire stone:W01-M58-6944/20-2
    Fire stone:W01-M58-6891/20-2Fire stoneW01-358-7180/22
    FIRE STONE W01 358 0226FIRE STONE 22T3 095 .0257
    FIRE STONE fole 210 095.008Fire ston:W01-358-7400/22
    Fire stone:W01-358-7405Fire stone:W01-358-7406
    Fire stone:W01-358-7424Fire stone:W01-358-7545
    Fire stone:W01-358-7550Fire stone:W01-358-7555
    Fire stone : W01-358-7136FIRE STONE W01-358-7146
    FIRE STONE W01-358-7143Fire stone:W01-358-7557
    Fire stone:W01-358-7781Fire stone:W01-095-0289
    Fire stone. W01-095-0508Fire stone.W01-358-9529
    Fire stone Style 21D-2
    Triple Convoluted
    Fire stone:W01-358-8008Fire stone:W01-358-8010
    Fire stone:W01-358-8027/38Fire stone:W01-358-8029
    Fire stone:W01-358-8030/38FIRE STONE W01 358 8006
    FIRE STONE FLEX 38R/38DFIRE STONE W01-358-7808
    FIRE STONE W01-358-7798FIRE STONE FLEX 313D
    FIRE STONE FLEX 313DFIRE STONE W01-358-7800
    FIRE STONE W01-358-7818FIRE STONE FLEX 313D

    Supports And Services


    • Our Industrial Air Springs product comes with comprehensive technical support and services to ensure that your experience with our product is seamless. Our team of experts is always available to assist with any technical issues that you may encounter with your air springs.
    • We also provide installation services to ensure that your air springs are installed correctly and function optimally. Additionally, we offer maintenance and repair services to keep your air springs in top condition and to extend their lifespan.
    • Our technical support and services are designed to help you get the most out of our product and to ensure that you have a positive experience with our brand.
