    W01-358-9978 Firestone Truck Shock Absorbers 1T15M-4 Rubber Bellow Air Spring

    Ask Lasest Price
    Brand Name : GUOMAT
    Model Number : 1T9978
    Certification : ISO/TS16949:2009
    Price : $79.9-99.9/pc
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000pcs/week
    Delivery Time : 2-8 work days
    • Product Details
    • Company Profile

    W01-358-9978 Firestone Truck Shock Absorbers 1T15M-4 Rubber Bellow Air Spring

    W01-358-9978 Firestone Truck Shock Absorbers 1T15M-4 Rubber Bellow Air Spring


    Carfitment & Part number



    OEM NO.



    Firestone W01-358-9978

    Firestone Bellows Number:1T15M-4
    ContiTech Number:67588, 69744, 9 10-14 P 959
    ContiTech Bellows Number:9 10-13.5
    Hendrickson Number:S-28929
    UPC: 767555127988
    MPN: W013589978



    1T9978 Air Spring Technical Data

    Extended Height:17.00 inches
    Compressed Height: 7.90 inches
    Top Plate Number:3210
    Top Plate Width:9.00 inches
    Piston Number:9656
    Piston Width:9.75 inches



    How to Choose the Right Suspension Air Spring for Your Truck

    Choosing the right air spring for your truck requires consideration of multiple factors, including vehicle type, load requirements, driving conditions, and compatibility. Here is a detailed selection guide:


    1. Determine vehicle information
    Truck model (such as Mercedes-Benz Actros, Volvo FH, Scania R series, etc.).

    Number of axles and suspension type (front suspension, rear suspension, trailer suspension, etc.).

    Year of production (different years may have design differences).


    2. Clarify technical parameters
    Load capacity (single-axle/dual-axle load, unit: kg or lbs).


    Installation dimensions:

    Diameter and height (free height/compressed height) of the air spring.

    Base fixing method (bolt hole spacing, flange type, etc.).

    Operating pressure range (usually 5~10 bar, heavy trucks may be higher).


    Product Picture

    W01-358-9978 Firestone Truck Shock Absorbers 1T15M-4 Rubber Bellow Air Spring
