    Goodyear Air Spring Flex No. 579913530 Contitech FS12010 CI G1/4 Single Bellows Cylinder

    Ask Lasest Price
    Brand Name : GUOMAT
    Model Number : 1B8-850
    Certification : ISO/TS16949, ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, Western Union
    Supply Ability : 1000PCS/Week
    Delivery Time : 5-8 Working Days
    • Product Details
    • Company Profile

    Goodyear Air Spring Flex No. 579913530 Contitech FS12010 CI G1/4 Single Bellows Cylinder

    Goodyear Flex No. 579913530 Contitech FS12010 CI G1/4 Single Bellows Cylinder



    Refer Number


    Goodyear Part number: 1B8-850
    Goodyear Part number: 1B8 850
    Goodyear Part number: 1B8850
    Goodyear Bellows number: 579-91-3-530
    Goodyear Bellows number: 579 91 3 530
    Goodyear Bellows number: 579913530

    Firestone Part number: W01-M58-6166
    Firestone Part number: W01M586166,
    Firestone Part number: W01-M58-6166
    Firestone Part number: WO1-M58-6166

    Firestone Part number: WO1M586166

    Firestone Part number:WO1 M58 6166

    Contitech Part number: FS 120-10 CI G 1/4
    Contitech Part number: FS 120 10 CI G 1/4
    Contitech Part number: FS120 10 CI G 1/4

    Details of Product


    Rubber Bellow Maximum Diameter: 336mm

    Structure: Single Convoluted Bellow

    Diameter of top cover plate: 228.6mm

    Diameter of bottom cover plate: 228.6mm

    Center to Center Diameter: 157.5mm

    Pneumatic Connection: G3/4

    Distance Air Hole Between Screw: 72.9mm


    Rubber Damage from Chemicals


    Grease and oil are common examples that can cause this condition after prolonged contact with the rubber flexible member.


    Possible causes:

    1. Excessive oil in the air supply.
    2. Excessive greasing of universal joints.
    3. Excessive greasing of the fifth wheel.
    4. Leaking seals in suspension components.
    5. Use of petroleum based cleaners on the air spring (use only soap and water for cleaning)


    Other Types Of Convoluted Goodyear Air Spring we have:
    Goodyear Air Spring OE NO.Goodyear Air Spring
    OE Bellows NO.
    Goodyear order NO.Bumper or notGoodyear Air Spring OE NO.
    1B8-564 Bellows Air Spring1B8-56420449825N1B8-564 Bellows Air Spring
    ENIDINE YI-1B8-5645799125640001920095534YENIDINE YI-1B8-564
    1B8-564 INTERNATIONAL 3547005C15799125640004220141113Y1B8-564 INTERNATIONAL 3547005C1
    1B8-5651B8-56520248442N1B8-565
    C 1B8-5605799125670009020810735YC 1B8-560
    P 1B8-5605799125680009120810607YP 1B8-560
    P 1B8-5505799125690009120811403YP 1B8-550
    C 1B8-5625799125700009020811604YC 1B8-562
    C 1B8-5645799125710009020811605YC 1B8-564
    C 1B8-8505799125720009020811606YC 1B8-850
    C 1B8-5505799126270009020806174YC 1B8-550
    1B5-8001B5-80020469101N1B5-800
    ENIDINE YI-1B5-8005799128000001920095537YENIDINE YI-1B5-800
    GOODYEAR 1B5-8015799128010000020607917YGOODYEAR 1B5-801
    ENIDINE YI-1B5-8015799128010001920095538YENIDINE YI-1B5-801
    1B5-8101B5-81020254245N1B5-810
    ENIDINE YI-1B5-8105799128100001920095539YENIDINE YI-1B5-810
    ENIDINE YI-1B5-8205799128200001920095540YENIDINE YI-1B5-820
    ENIDINE YI-1B5-8215799128210001920224307YENIDINE YI-1B5-821
    ENIDINE YI-1B6-8315799128310001920095541YENIDINE YI-1B6-831



    The Related Picture of 1B8-850

    Goodyear 1b8-850/579913530 Convoluted Air Spring Cross Contitech Fs12010ci G1/4 BagsGoodyear 1b8-850/579913530 Convoluted Air Spring Cross Contitech Fs12010ci G1/4 Bags
