Brand Name : | GUOMAT |
Model Number : | 2B12-346 |
Certification : | ISO/TS16949, ISO9001 |
Price : | Negotiable |
Payment Terms : | L/C, D/A, D/P, Western Union |
Supply Ability : | 1000PCS/Week |
Delivery Time : | 5-8 Working Days |
Double Bellow Air Spring Goodyear 2B12-346 for Histeer 10315 1/4NPTF Air Inlet
Product Introduction
The GUOMAT 2B12-346/W013587550 air spring is designed to maintain
heavy-duty truck bodies at a consistent height from the road,
ensuring stability and adaptability for any load. This durable air
spring not only provides secure and dependable transportation but
also offers flexibility by allowing the truck’s body height to be
adjusted for ramp alignment or platform compatibility. Trust GUOMAT
to be your go-to choice for heavy-duty performance.
Manufacturer OEM Number
Manufacturer | OEM REFERENCE |
GOODYEAR NO. CONTITECH | 2B12-346/2B12 346/2B12346 FD 331-26 480/FD 331-26 541 / FD 331-26 541 |
Fire stone Air Spring Bellows Number | 228-1.5 |
Fire stone Air Spring part Number | W01 358 7550 / W01 358 7555 / W01-358-7550 / W01-358 -7555 |
GOODYEAR | 2B12-440 / 2B12-346 / 2B12 440 / 2B12 346 |
GOODYEAR-FLEXMEMBER | 578-92-3-315 / 578923315 / 578 92 3 315 |
Triangle | 6375/4480 |
HISTEER | 10315 |
WATSON & CHALIN | AS-0087 |
Histeer | 10315 |
HS INDUSTRIES/LINK # | 10315 |
Top Plate Number | 3271 |
Piston Number | 3183 |
Technical Specifications
Top Cover Plate Screw (Nut) Tooth: 1 pcs X M12
Top Cover Plate Combination Nut: M20,M12
Screw Center Distance of Top Cover Plate: 157 mm / 6.2 inches
Bottom Cover Plate Screw (Nut) Tooth: 2 pcs X M10
Screw Center Distance of Bottom Cover Plate: 157 mm / 6.2 inches
Gas Hole / Air inlet : M12 , Combination Stud/Air Inlet Stud
Top Cover Plate Diameter (Width): 224.5 mm / 9.00 inches
Bottom Cover Plate Diameter (Width): 224.5 mm / 9.00 inches
Rubber Bellows MAX Diameter : 343 mm / 9.7 inches
Compressed Height: 104 mm / 4.1 inches
Maximum Height: 363mm / 14.3 inches
Working Stroke : 259 mm / 10.2 inches
With Bumper Block
With Girdle Hoop: One Pieces of Girdle Hoop
Rubber Damage Caused by Chemicals
Prolonged contact with substances like grease and oil can harm the
rubber flexible component of air springs. Below are potential
causes of such damage:
- Excessive oil contamination in the air supply.
- Over-greasing of universal joints.
- Over-greasing of the fifth wheel.
- Leaking seals in suspension components.
- Using petroleum-based cleaners on the air spring (always clean
with soap and water only).
Real Pictures of Details
![]() |
