    Gantry Front Suspension System Hungarian RABA Gantry Bridge GFN075

    Ask Lasest Price
    Brand Name : GUOMAT
    Model Number : GFN075
    Certification : ISO/TS16949:2009
    Price : Negotiable
    Payment Terms : T/T, Western Union,Paypal or Others
    Supply Ability : 1000pcs/week
    Delivery Time : 2-8 work days
    • Product Details
    • Company Profile

    Gantry Front Suspension System Hungarian RABA Gantry Bridge GFN075

    Gantry Front Suspension System Hungarian RABA Gantry Bridge GFN075


    GUOMATGFN075 Specifications and Detail Technical Parameters


    1,suspension GFN075

    Gantry Front Suspension System
    Model:GFN075
    Four-link brake bridge in front of air suspension system; introduction of Hungarian RABA gantry bridge to introduce disc brakes. The price is 30% -40% lower than imported similar products, which not only saves costs, but also brings you comfort.

    Gantry Front Suspension System Hungarian RABA Gantry Bridge GFN075


    2,suspension GCN130

    Air suspension system in the gantry bridge
    Model:GCN130
    Four-bar linkage, large span four air springs, four shock absorbers, low floor, all-air suspension system, the introduction of Hungarian ABA technology, imported disc brakes, imported main reduction and differential, lower prices have advantages Save 30% -40% than imported similar products

    Gantry Front Suspension System Hungarian RABA Gantry Bridge GFN075


    3,suspension GRN075

    With the moving bridge air suspension system
    Model:GRN075
    Four-link mechanism, large-span airbag air spring, air suspension system driving the axle, steering booster, automatic reversing lock, high-speed automatic lock function

    Gantry Front Suspension System Hungarian RABA Gantry Bridge GFN075


    Technical parameters


    ModelAFN075 Gantry bridge before the air suspension systemACN130 Air suspension system in the gantry bridgeARN075 With the moving bridge air suspension system
    Rated shaft load7500kg13000kg7500kg
    Frame width940mm(Channel width can be achieved 720-780mm)940mm940mm(Channel width can be achieved 780mm)
    Tread1980-2020mm1800-1860mm1980-2020mm
    Axle dynamic travel160mm(upwards:80mm,downwards:80mm)190mm(upwards:90mm,downwards:100mm)160mm(upwards:80mm,downwards:80mm)
    Airbags span1200-1300mm1500mm1200-1300mm
    The system is biased1.15-1.3Hz1.15-1.3Hz1.15-1.3Hz

    Gantry Front Suspension System Hungarian RABA Gantry Bridge GFN075

    Gantry Front Suspension System Hungarian RABA Gantry Bridge GFN075
