    FD 210-22 DS Double Convoluted Air Spring With Dismountable Plates G1/2 Air Inlet

    Ask Lasest Price
    Brand Name : GUOMAT
    Model Number : 2B210-22
    Certification : ISO/TS16949:2009
    Payment Terms : T/T, Western Union,Paypal or Others
    Supply Ability : 1000pcs/week
    Delivery Time : 2-8 work days
    • Product Details
    • Company Profile

    FD 210-22 DS Double Convoluted Air Spring With Dismountable Plates G1/2 Air Inlet

    FD 210-22 DS Double Convolution Air Bag With Dismountable Plates, G1/2 Air Inlet


    ❶Nut/ Blind Nut


    Top cover screw (nut) teeth: 4 X M8
    Top cover screw center distance: 181 mm
    Bottom cover screw (nut) teeth: 4 X M8
    Bottom cover screw center distance: 181 mm


    ❷ air hole / air inlet / air connector
    Air vent / air inlet: G1/2
    Center distance between air inlet and nut:90.5 mm


    ❸ cover
    Top cover diameter (width): 210 MM
    Bottom cover diameter (width):210 MM


    ❹Rubber bellows


    Rubber bellows natural diameter: 250 mm
    Rubber bellows MAX diameter: 270 mm
    Compressed height: 81 mm / 4.12 inches
    Minimum bump height: 75 mm
    Maximum height: 300 mm
    Rubber bellows only:66993
    Working stroke: 225


    ❺ bumper block / buffer block
    No Bumper Block
    Twisted waist/waist ring
    Girdle Hoop: a belt hoop



    Vibration isolation – dynamic characteristic values

    Design height H: recommended 220mm, minimum 200mm


    Pressure p [bar]345678Vol. V [l]8
    Force (Load) [kN]6.79.211.513.916.318.76.7
    Spring rate [N/mm]100123.5148171194.5218.57.25.2
    Natural frequency [Hz]1.91.81.81.81.71.73.3


    "Pneumatic application – static characteristic values
    Force F [kN]"


    Pressure p [bar]345678Vol. V [l]
    Height H [mm]2505.287.229.1611.213.215.18
    2007.6610.31315.718.421.16.7
    1509.9813.416.720.223.6275.2
    10012.416.520.624.828.9333.3
