Brand Name : | GUOMAT |
Model Number : | W01-358-7994 |
Certification : | ISO/TS16949:2009 |
Price : | $69.9-79.9/pc |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 1000pcs/week |
Delivery Time : | 2-8 work days |
Air Lift Bellows Convoluted Air Spring Contitech FT330-29 546/Firestone W013587994
Quack Detail
Item | Air Spring | Model | W01-358-7994 |
Condition | Brand new | Warranty | 1 Year |
Trade Term | FOB,CNF,EXW | Packing | Carton |
Delivery | 2-8working days | Material | Rubber+Steel |
Payment | TT,LC,Western Union | MOQ | 1 PC |
Technical parameters
❶Nut / Blind Nut
Top Cover Plate Screw (Nut) Tooth : 1pcsX3/8-16UNC
Screw Center Distance of Top Cover Plate : 89 mm
Bottom Cover Plate Screw (Nut) Tooth : 2pcsX3/8-16UNC
Screw Center Distance of Bottom Cover Plate : 140 mm
Screw Center Distance of Bottom Cover Plate : 157.5 mm
❷ Gas Hole / Air inlet / Air Fitting
Gas Hole / Air inlet : 1/4 N P.T.F. / 1/4NPTF
❸ Cover Plate
Top Cover Plate Diameter: 231 mm
Bottom Cover Plate Diameter: 231 mm
❹Rubber Bellows
Rubber Bellows MAX Diameter: 330 mm
Rubber Bellows Natural Diameter :300 mm
The Working Stroke : MAX 460 mm to MIN 130 mm
Maximum Height : 460 mm
Minimum Height :130 mmx
Compression Height : 330 mm
❺ Bumper block / Buffer block
With Bumper Block Or Without Bumper Block
❻ Girdle Hoop / Girdle Ring
With Girdle Hoop :Two Pieces of Girdle Hoop
Cross Information
Firestone W01-358-7994
Contitech FT 330-29 546 / 64572
Goodyear 3B12-328
Triangle 4546/6364
Watson&chalin AS-0019-F
Euolid/meritor After market E-FS7994
GUOMAT Product Picture
![]() |
