1T15M-4 FIRESTONE W01-358-9010 Suspension Air Spring 566-24-3-076 Goodyear 1R12-352

GUOMAT 1T9010 details OEM References

GUOMAT 1T8966 Technical parameters

❶ screw bolt / Stud

Top Cover Plate screw bolt / Stud Tooth :2 pcs M 12

Screw Center Distance of Top Cover Plate : 210 mm

❷ Gas Hole / Air inlet /Air Fitting

Gas Hole / Air inlet : M22x1,5.

Distance Between Gas Hole and Stud :25 mm

Distance Between Gas Hole and Central axis :95 mm

❸ Cover Plate

Top Cover Plate Diameter: Ø311.5 mm

❹Rubber Bellows

Rubber Bellows Natural Diameter: 355 mm

❺ Bumper block / Buffer block

Bumper Block height :30 mm

❻ Bottom Piston

Bottom Piston Diameter : Ø256mm

Bottom Piston Height :188.5 mm

❼ Piston Bolt

Piston Bolt Tooth : M16

12 pieces of Bolt

Middle inside between center Bolt : 70 mm

Middle faster between center Bolt : 120 mm

Inside the most close Bolt :45 mm

Inside and the beside Bolt:80 mm

Continental ContiTech number 9 10-14 P 345,

ContiTech order number 64258,

Hendrickson number S-2827,

Hendrickson number S-11566,

Reyco number 12928-01,

Ridewell number 1003589010C,

Watson & Chalin number AS-0019203I-0044,

Automann-Firestone,

Watson & Chalin number AS- 00192031 -9010,

Firestone style number 1T15M-4,

FleetPride number AS9010,

Goodyear number 1R12-421,

Goodyear number 1R12-352,

Goodyear Flex No. 566243076,

Taurus number 6362,

Triangle number AS-8345,

TRP number AS90100

Guangzhou Guomat Air Spring Co., Ltd. is located in Guangzhou, about 15min’s drive from Baiyun Airport. Our mainly products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles’ seat, luxurious car and industrial machine field.

GUOMAT Factory gate：

Established in 2008, Our company covers 20,000㎡ and is located in Taihe Town Baiyun District. With the rapid development of our company, we are equipped with modernized workshop and advanced rubber air springs equipments now. We are the first company who started air spring business and has become one of the largest air spring manufacturing bases in China.

In 2017, we launched a collaboration with High Tech of US customers to customize the products of our customers and the logo of our customers. Every year, there are about 10,000 orders. In continuous cooperation, the products meet the international inspection standard ISO/TS16949:2009, and the customers are very satisfied with the products produced. This is our high recognition from American customers and also gives us Great motivation.

In 2018, we started cooperation with German GmbH, mainly industrial air springs, which are suitable for industrial equipment. We have successfully developed and produced the natural air-seal of the skin to reach the 700mm flanged air spring, the customer's annual demand is a few hundred.

With the development of business and demand for customers, our company introduced business with TomLog Corporation in 2010, our strategic cooperative partner in Taiwan. Then we developed air compressor program and air spring related business, in 2015, America Goodyear Corporation met with the transfer of shares in the North American plant, our company was granted with sale agent for air springs in China, providing more choice for our customers. Our company adopts the most advanced domestic air spring processing equipment and international production technology. Combined with unique production process, our company strictly execute international standards for production and spare no efforts to create the world-class products. We will endeavor to make air spring widely used at home and abroad, and let more and more customers to enjoy the best damping effect.
