    Firestone W01-095-0500 Truck Air Springs Contitech 4913NP02 Phoenix 1D28H-16

    Ask Lasest Price
    Brand Name : GUOMAT
    Model Number : 1T4913NP02
    Certification : ISO/TS16949
    Price : $59-159/pc
    Payment Terms : T/T, Western Union,paypal or others
    Supply Ability : 1000pcs/week
    Delivery Time : 2-8 work days
    • Product Details
    • Company Profile

    Firestone W01-095-0500 Truck Air Springs Contitech 4913NP02 Phoenix 1D28H-16

    FIRESTONE W01-095-0500 Truck Air Springs CONTITECH 4913NP02 PHOENIX 1D28H-16


    Cross ReferencesVehicle​​s OEM References
    CONTITECH 4913 N P02SCANIA 1379392
    FIRESTONE W01-095-0500

    W010950366 / W01 095 0366 / W01-095-0366

    W010950500/ W01 095 0500/ W01-095-0500

    W01M588098 / W01-M58-8098 / W01 M58 8098

    SCANIA 1440294
    FIRESTONE 1T19F-14 W01 095 0366SCANIA 1543691
    GOODYEAR 1R14-753Meritor MLF7081
    PHOENIX 1D 28 H-16;1D28H-16Scania 1402423
    DUNLOP FR D14B42 CONTITECH 4913NP02
    CF GOMMA 1T19E-93 CF GOMMA 206201
    TAURUS KR 625-16
    Granning 16105
    WABCO 951 814 753 0 WABCO 9518147530

    1T4913NP02 Technical parameters


    Screw Bolt / Stud

    Top Cover Plate screw bolt / Stud Tooth :2 pcs M12X1.5

    Distance Between Two Stud :144 mm

    Gas Hole / Air inlet / Air Fitting

    Gas Hole / Air inlet : M16X1.5.

    Distance Between Air inlet and Stud: 177 mm and 33 mm

    Cover Plate

    Top Cover Plate Diameter: Ø286 mm

    Rubber Bellows

    Rubber Bellows Natural Diameter: 330 mm

    Rubber Bellows MAX Height : 797 mm

    Rubber Bellows MIN Height :235 mm

    Working stroke : 562 mm

    Bumper block / Buffer block

    Without Bumper Block

    Bottom Piston

    Bottom Piston Diameter : Ø230 mm

    Bottom Piston Height :210 mm

    Piston Bolt

    Piston Bolt Tooth : M16X2.0 and Ø16

    2 pieces of Bolt

    Distance Between Two Bolt : 70 mm


    Interchange Part Number:W01-095-0500, W01-M58-8098Other Part Number:1R14753, D14753, 34913K, 4913NP02
    Superseded Part Number:1D28H16, MLF7081, 1440294, 1379392
    Placement on Vehicle:Left, Right, Front, RearType:Air Suspension Spring
    Fitment Type:Direct ReplacementSize:Single Dimension(CM) 42.00(Length)*30.00(Width)*30.00(Height)
    Single Weight(KG):13.400Upper Mounting Isolator Included:No Isolator Required
    Lower Mounting Isolator Included:No Isolator RequiredUpper Mount Type:Stud
    Lower Mount Type:StudIncluded Hardware:None
    Drive Layout:UniversalPlatform:Universal
    Custom Bundle:YesMaterial:Iron,Aluminium Alloy,Rubber
    Quantity:PairManufacturer Warranty:1 Year
    OE Spec or Performance/Custom:OE SpecAdjustable:Yes
    Features:SealedBrand:Guomat or Netural
    UPC:Does not applyManufacturer Part Number:1T4913NP02

    566-24-3-522 / 566 24 3 522 /566243522

    SCANIA 1440294

    SCANIA 1510195

    SCANIA 1543691

    SCANIA 1379392

    SCANIA 1379393

    SCANIA 1379394


    Scania

    1440294
    1379392
    1379393


    FIRESTONE

    1T19F-14

    Airtech

    34913K


    Cf Gomma

    206201
    1T19E93


    Contitech

    4913NP02


    Dunlop

    00937AAP


    C282H
    2821600
    V1D28H16
    14913K


    Goodyear

    1R14753
    D14753


    Phoenix

    1D28H16


    Meritor

    MLF7081



    The cover plate and the piston of 4913NP02


    4913NP02 CONTITECH has two screw and on air inlet on the cover of the steel plate.The air inlet is not in the middle of these two screw but is in the side of screw rod.

    a single screw rod is prominent out of the base.


    Firestone W01-095-0500 Truck Air Springs Contitech 4913NP02 Phoenix 1D28H-16Firestone W01-095-0500 Truck Air Springs Contitech 4913NP02 Phoenix 1D28H-16Firestone W01-095-0500 Truck Air Springs Contitech 4913NP02 Phoenix 1D28H-16
