Brand Name : | Goodyear |
Model Number : | 2B9-250 |
Certification : | ISO/TS16949:2009 |
Price : | $159.9-199.9/pc |
Payment Terms : | T/T, Western Union, L/C |
Supply Ability : | 1000pcs/week |
Delivery Time : | 2-8 work days |
MOQ : | 1 Piece |
OEM Goodyear Air Spring Bellows 2B9-250 Double Convoluted Air Super
Cushion 578-92-3-206
Product Description
The 2B9-250 Goodyear air spring is an air spring or bladder used in
vehicle suspension systems. It is designed to provide support and
cushioning to the vehicle, helping to absorb shock and vibration
while improving ride comfort and stability. 2B9-250 Goodyear air
springs can also be installed in industrial equipment to reduce
vibration and noise generated by machines.
Manufacturer: GOODYEAR
Manufacturer part number: Goodyear 2B9-250
Manufacturer part number: Goodyear 2B 9-250
Manufacturer part number: Goodyear 2B9 250
Manufacturer part number: Goodyear 2B 9 250
Manufacturer part number: Goodyear 2B9250
Manufacturer bellows number: Goodyear 578923206
Manufacturer bellows number: Goodyear 578 92 3 206
Manufacturer bellows number: Goodyear 578-92-3-206
2B9-250 Goodyear Air Spring is Cross-referenced with the Following
Numbers
AUTOMANN | REYCO |
Technical Data: 2B9-250 Goodyear Air Spring
Top cover diameter: 6.40 inches
Air inlet specification: 1/4 NPTF
Bolt or Stud: 1/2-13 or 1/2-20
Distance between air hole and stud: 1.75 inches
Center distance between studs: 3.50 inches
Bottom cover diameter: 6.40 inches
Tapped Hole: 1/2-13
Maximum height: 12.2 inches
Minimum height: 3.5 inches
Applications of 2B9-250 Goodyear Air Spring
Trucks: It is commonly used in trucks, especially in the suspension
systems of heavy-duty trucks and semi-trailers. The air spring
helps to improve ride comfort and stability, particularly when
carrying heavy loads.
Trailers: The 2B9-250 Goodyear Air Spring is often used in the suspension
systems of trailers, including flatbed trailers, container
trailers, and other types of hauling trailers. It helps to
distribute weight evenly and minimize vibrations during transport.
Buses: Many buses, including city buses and intercity coaches, use air
springs in their suspension systems. The 2B9-250 Goodyear Air
Spring can be found in these applications, providing a smoother and
more comfortable ride for passengers.
Industrial Equipment: The 2B9-250 Goodyear Air Spring is also used in various types of
industrial equipment, such as construction machinery, agricultural
equipment, and off-road vehicles. It helps to absorb shocks and
vibrations, improving the overall performance and durability of
these machines.
![]() |
