4881 NP 02 / 4881NP02 Air Shocks For Trucks W01 M58 8602 1R14-757 for IVE-CO BPW

OEM Cross :

GUOMAT 1T8602

CONTINENTAL
4881 NP02
CONTITECH
50495
DUNLOP FRANCE
D1 4B37
FIRESTONE REF.
W01 M58 8602
STYLE NO.
1T66F-7.0
GOODYEAR
1R14-724
GRANNING
15905
PHOENIX
1 DK32 K
VIBRACOUSTIC
V1D32 K

AIRTECH
131862
AIRTECH PROD. N0.
34881-01K
AUTOMINT
6115
BL ACKTECH
RML 75992 C

GUOMAT 1T4881NP02 Technical parameters

❶ screw bolt / Stud

Top Cover Plate screw bolt / Stud Tooth :2 pcs M 12

Distance Between Stud and Central axis : 25 mm

❷ Gas Hole / Air inlet /Air Fitting

Gas Hole / Air inlet : M22x1.5.

Distance Between Gas Hole and Stud :70mm

Distance Between Gas Hole and Central axis :95 mm

❸ Cover Plate

Top Cover Plate Diameter: Ø311.5 mm

❹Rubber Bellows

Rubber Bellows Natural Diameter: 355 mm

❺ Bumper block / Buffer block

Bumper Block height :30 mm

❻ Bottom Piston

Bottom Piston Diameter : Ø256mm

Bottom Piston Height :148 mm

❼ Piston Bolt

Piston Bolt Tooth : M16

12 pieces of Bolt

Middle inside between center Bolt : 70 mm

Middle faster between center Bolt : 120 mm

Inside the most close Bolt :45 mm

Inside and the beside Bolt:80 mm

4881 NP 02 / 4881NP02 Air Shocks for BPW

Contitech
4881 NP02with piston
Firestone
W01-M58-8602
Goodyear
1 R14-757
566-28-3-505
Phoenix
1 DK32K
Dunlop
D14B37

FIRESTONE 1T66F-7.0

W01 M58 8602

GOODYEAR 1R14-724

The base of 4881NP02 Air Shocks has 12 piece of screw for connection.

Guangzhou Guomat Air Spring Co., Ltd. is located in Guangzhou, about 15min’s drive from Baiyun Airport. Our mainly products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles’ seat, luxurious car and industrial machine field.

GUOMAT Factory gate：

Established in 2008, Our company covers 20,000㎡ and is located in Taihe Town Baiyun District. With the rapid development of our company, we are equipped with modernized workshop and advanced rubber air springs equipments now. We are the first company who started air spring business and has become one of the largest air spring manufacturing bases in China.

In 2017, we launched a collaboration with High Tech of US customers to customize the products of our customers and the logo of our customers. Every year, there are about 10,000 orders. In continuous cooperation, the products meet the international inspection standard ISO/TS16949:2009, and the customers are very satisfied with the products produced. This is our high recognition from American customers and also gives us Great motivation.

In 2018, we started cooperation with German GmbH, mainly industrial air springs, which are suitable for industrial equipment. We have successfully developed and produced the natural air-seal of the skin to reach the 700mm flanged air spring, the customer's annual demand is a few hundred.

With the development of business and demand for customers, our company introduced business with TomLog Corporation in 2010, our strategic cooperative partner in Taiwan. Then we developed air compressor program and air spring related business, in 2015, America Goodyear Corporation met with the transfer of shares in the North American plant, our company was granted with sale agent for air springs in China, providing more choice for our customers. Our company adopts the most advanced domestic air spring processing equipment and international production technology. Combined with unique production process, our company strictly execute international standards for production and spare no efforts to create the world-class products. We will endeavor to make air spring widely used at home and abroad, and let more and more customers to enjoy the best damping effect.
