Flange Connection Air Spring Guomat 150076H-1 For Papermaking Equipment

Guomat 150076H-1 Single Convoluted Air Spring Specifications

❶Nut / Blind Nut

Top Cover Plate Screw number: 4 pcs

Bottom Cover Plate Screw number : 4 pcs

❷ Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : 1/4NPTF

❸ Cover Plate

Top Cover Plate Diameter: 115 mm

Bottom Cover Plate Diameter: 115 mm

❹Rubber Bellows

The Opening Diameter:88 mm

The Height Of Opening:15 mm

Rubber Bellows Through Diameter: 104 mm

Rubber Bellows Natural Diameter : 150 mm

The Working Stroke : MIN 75 mm to MAX 260 mm

Rubber Bellows Natural Height :76 mm

❺ Bumper block / Buffer block

Without Bumper Block

❻ Girdle Hoop / Girdle Ring

Without Girdle Hoop

Technical performance parameter list of 150076H-1 air spring:

Air springs have solved vibration and noise problems in multiple applications, such as:

• Vibrating shaker screens
• Vibrating conveyors
• Precision electronic equipment• Vibrating hoppers and bins
• Isolation of flex testing machines
• Isolation of forging hammers
• Thin plate welding clamping device
• Isolation of frozen food and plastic pellet compaction systems
• Isolation of cabs on dredging machines
• Precision cutting machine bookbinding magazine
• Isolation of computer and spectrometers from outside vibration
• Isolation of oscillating equipment

Guangzhou Guomat Air Spring Co., Ltd. is located in Guangzhou, about 15min’s drive from Baiyun Airport. Our mainly products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles’ seat, luxurious car and industrial machine field.

GUOMAT Factory gate：

Established in 2008, Our company covers 20,000㎡ and is located in Taihe Town Baiyun District. With the rapid development of our company, we are equipped with modernized workshop and advanced rubber air springs equipments now. We are the first company who started air spring business and has become one of the largest air spring manufacturing bases in China.

In 2017, we launched a collaboration with High Tech of US customers to customize the products of our customers and the logo of our customers. Every year, there are about 10,000 orders. In continuous cooperation, the products meet the international inspection standard ISO/TS16949:2009, and the customers are very satisfied with the products produced. This is our high recognition from American customers and also gives us Great motivation.

In 2018, we started cooperation with German GmbH, mainly industrial air springs, which are suitable for industrial equipment. We have successfully developed and produced the natural air-seal of the skin to reach the 700mm flanged air spring, the customer's annual demand is a few hundred.

With the development of business and demand for customers, our company introduced business with TomLog Corporation in 2010, our strategic cooperative partner in Taiwan. Then we developed air compressor program and air spring related business, in 2015, America Goodyear Corporation met with the transfer of shares in the North American plant, our company was granted with sale agent for air springs in China, providing more choice for our customers. Our company adopts the most advanced domestic air spring processing equipment and international production technology. Combined with unique production process, our company strictly execute international standards for production and spare no efforts to create the world-class products. We will endeavor to make air spring widely used at home and abroad, and let more and more customers to enjoy the best damping effect.
